非理想因素對基于CCⅡ全集成連續時間濾波器的影響
ANALYSIS OF NONIDEAL EFFECTS ON CCII-BASED FULLY INTEGRATED CONTINUOUS-TIME FILTERS
-
摘要: 本文分析了用CCII實現的積分器的誤差函數。在此基礎上,研究了由雙積分器回路構成的基于CCII全集成連續時間帶通濾波器;分析了中心頻率p,和Qp,與誤差函數幅值E和相位E之間的關系;探討了CCII非理想因素對p,和Qp的影響。所得結論為設計基于CCII的MOSFET連續時間高階濾波器提供了依據和改進途徑。
-
關鍵詞:
- 電流傳輸器; 全集成濾波器; 非理想分析
Abstract: The error functions of CCII-based integrators are analysed. On this basis, the fully integrated CCII-based continuous-time bandpass filters consisted of double integrator loops are studied, and the relationship between the centre frequency p and Qp and the magnitude E and the phase E of the error function is also discussed. The effects of nonideal CCII are considered in detail. The conclusions obtained may provide foundation and improvement for the design of CCII-based MOSFET continuous-time higher order filters. -
Sedra A S, Robert G W, Gohn F. IEE Proc.-G, 1990, 137(2):78-87.[2]Kumar U, Shukla S K. Microelectronics, J., 1989, 20(5):24-46.[3]Liu S I, Tsao H W, Wu J. IEE Proc.-G, 1991, 138(2):210-216.[4]陳莉,邱關源.基于非理想CCII電流模式積分器的性能分析,中國電子學會電路與系繞學會第十一屆年會論文集.桂林:1993年11月,509-512.[5]Khoury J, Tsividis Y I. IEEE Trans. on CASE 1987, CAS-34(8):862-875.[6]Bingxue S, Khoury J, Tsividis Y I. IEEE Trans, on CAS, 1986, CAS-33(7):648-651.[7]Geiger R L. Bailey G R. IEEE Trans, on CAS, 1982, CAS-29(9):595-603. -
