旋轉模式濾波器的設計
DESIGN OF A ROTATING MODE FILTER
-
摘要: 本文給出了扇形波導中的TE模場解。討論了用扇形波導作為旋轉模式濾波器的基本原理。介紹了這種濾波器的設計方法。給出了以TE03模工作時這種濾波器的實驗結果。
-
關鍵詞:
- 扇形波導; 旋轉模式; 濾波器
Abstract: The solution of the electromagnetic field is given for TE mode in a infinite long fan-shaped waveguide. The basic principle of a rotating mode filter with fan-shaped waveguide is presented. The design method for the filter is discussed by a practical example. The good experimental result of the filter is reached for TE03 mode operation. -
Kimery H D，et al．Method and device for microwave sintering large ceramic articles．U．S．Patent， 4963709，Oct．16，1990．[2]Miyake S，et al．Focusing of high power millimterwave radiation by a quasi-optical antenna system． Int．J．Electronics，1991，70(5)：979-988．[3]Luo J，et al．Analysis of a mode filter．4th International Conference on Millimeter Waves and Far Infrared Science and Technology，Beijing：1996，230-932． -
